Automatic Bottom Assembling and Handle Machine

• Four Independent Stitching Units: Four stitching heads, each equipped with a high-performance motor and digital inverter for precise, efficient operation. Self-centering riveting units ensure accurate positioning.

• Servo-Driven Transport System: Four 1-inch conveyor chains powered by two servo motors with digital drives provide reliable material transport.

• Advanced PLC Control: Fully automated operation managed by a PLC system with a touchscreen control panel for easy programming.

• Programmable Production: Store up to 10 different box configurations for flexible production.

• Fast Size Adjustment: Motorized width and length adjustments enable quick, convenient changeovers between box sizes.

 Automatic Frame Production Machine

This machine features four MONOBLOCK stitching groups, each driven by a high-precision motor.

 Materials are transported by four 1" chains for heads and boards, plus four additional 1" chains for secondary boards, while four pneumatic feeders handle board feeding.

Two speed-adjustable conveyors manage the entrance of the heads. Every function is managed by an advanced controller with a touch-screen panel, and up to 20 programs can be stored in memory.

Electric motors for width and length adjustment make size changeovers quick and effortless.

Automatic Frame Stitching Machine

• Four high-performance stitching heads work simultaneously for excellent stitching quality
• Easy, programmable adjustment of stitches, production and all other machine operations, with memory storage for many different box types
• Fast, accurate case dimension adjustment using position indicators and electric motors
• Quick leaf position adjustment thanks to special chains, with no need to replace spacers
• High-technology SERVO motors drive the stitching heads, ensuring precise stitch positioning
• Automatic feeding of ends through direct connection with the SMA-110/4
• Air-conditioned electrical cabinet
• Special safety devices (CE certified)

Automatic Bottom Feeder Machine

• Bottom feed: The bottoms are advanced by two chains fitted with special grippers.
• Variable chain speed: Chain speed is adjusted by an inverter.
• PLC control: All operations are controlled by a PLC.

Automatic Cutting Machine for Rectangles

• Magazine with 3 free stages, each holding 5 rectangles
• Automatic block feeding by chain up to the cutting position
• Automatic front-face cutting (cleaning cut) before the cutting cycle begins
• Rectangle end detector with an automatic system for removing small cut-off pieces
• Easy, fast and accurate adjustment of cutting dimensions
• Touch-screen control of all functions
• CE compliant

Automatic Group of Machines for Heads Production

• High precise technology
• Simple construction
• Fast and easy adjustments
• Easy to operate
• Low maintenance cost
• Low noise level
